通道數 Number of
channels |
2 ch |
|
整台擴大機最大輸出 Peak
total output all channels driven |
14000 W |
|
每通道最大輸出電壓 Peak
output voltage per channel |
195 V |
|
每通道最大輸出電流 Max.
output current per channel |
83Arms |
|
最大輸出功率 Max.
Output Power |
2Ω
|
4Ω |
8Ω |
16Ω |
|
每通道 Per ch. (all
ch.’s driven) |
7000 W |
4400 W |
2350 W |
1200 W |
|
橋接時每通道 Bridged
per ch. |
- 3)
|
14000 W |
8800 W |
4700W |
|
在增益35dB及輸出電壓100V時
Performance with Gain |
|
|
全頻總諧波失真率 THD 20
Hz - 20 kHz for 1 W |
<0.1% |
|
1KHz總諧波失真率
THD at 1 kHz and 1 dB below clipping |
<0.05% |
|
雜訊比 Signal To
Noise Ratio |
>112dBA |
|
通道分離度(串音)
Channel separation (Crosstalk) at 1 kHz |
>70dB |
|
頻率響應 Frequency
response(1W into 8Ω)
+0/-3 dB |
2Hz-34.2kHz |
|
輸入阻抗
Input impedance |
20 kΩ |
|
共模拒斥比
Input Common Mode Rejection, CMR |
54dB |
|
輸出阻抗(100Hz)
Output impedance @ 100 Hz |
56mΩ |
|
輸出電壓限制調整
Voltage Peak
Limiter (VPL)2), max. peak output |
|
每通道限制選擇
VPL, selectable per ch |
195,170,140,116,100,80,66,54V |
|
橋接限制選擇
VPL, selectable when bridged 1) |
390,340,280,232,200,160,132,108V |
|
電壓最大限制模式選擇
Voltage Peak
Limiter mode (per ch.) |
Hard / Soft |
|
電平增益
Gain and Level |
|
擴大器增益選擇
Amplifier gain selectable (all channels)
1)
–rear-panel
switches |
23,26,29,32,35,38,41,44dB |
|
系統默認增益值
Default gain |
38 dB |
|
工作電壓範圍
Operating voltage,115V nominal 4) |
100-126V |
|
尺寸Dimensions
(W×H×D) |
(W)483mm×(H)88mm×(D)410mm |
|
重量Weight |
13 kg |
|
Note 1) 每通道在橋接的模式下可自動補償-6dB
Automatic -6 dB gain
compensation when bridging channels |
|
Note 2) PAL的電壓限制模式可以提供大功率輸出時仍然保持電源工作安全及防止過量的電流導致斷路器跳閘
PAL can reduce the maximum output
power to keep the power supply operating safely, and/or to
prevent excessive current draw tripping the mains breaker.
Refer to Operation Manual. |
|
Note 3) 該擴大器由於機身散熱及電源供應等條件限制下及輸出功率並不明顯高於單獨聲道的狀況下，不便使用於此條件下The
amplifier will be fully operational at bridge-mode 2 ohm
loads, but due to physical constraints in the construction,
the max. output power will not be significantly higher than
running individual channels and therefore not stated here. |
|
Note 4)
有115V及230V不同電壓的版本，擴大器內部不可選擇Separate
230 V or 115 V versions available. Not selectable on the
amplifier. |
