規格表
/ Specifications
NUQ-12 |
頻率響應 |
Frequency Response |
50Hz-20KHz(±3dB) |
頻率下限 |
Low Frequency Limit |
45Hz(-10dB) |
單元組成 |
Drivers |
1×12”(300mm)/3”(75mm)voice coil LF driver |
|
|
1×1”(25mm) compression driver |
額定功率 |
Rated Power |
450W r.m.s ,1800W peak |
靈敏度 |
Sensitivity |
97dB/1m/1w |
最大聲壓級 |
Maximum SPL |
122dB continuous,128dB peak |
額定阻抗 |
Impedance |
8Ω |
擴散角度 |
Dispersion |
90°×40° |
分頻點 |
Crossover Frequency |
2KHz |
輸入方式 |
Connectors |
2×NL4/1+1- |
吊裝附件 |
Fittings |
12×M8
inserts for wall bracket 1×Top hat fltting |
尺寸W×H×D(mm) |
Dimensions |
寬373×高340×深655(mm) |
重
量 |
Weight |
22kg |
|
