Thank you for
purchasing the KING STAGE ZM410 Zone Distribution Mixer. We are sure
that you will find this equipment to be the finest product of its kind
in the price manual before setting up to operation.
The ZM410 Zone Distribution Mixer designed with
high quality ICs, to provide outstanding signal to noise, THD, and
frequency response. One of this product features is that it can be used
as a distributor or as a mixer. It has two line inputs, from either
line. When button Mono is normal position, signal from Line 1 Channel L
and Line 2 Channel can be mixed and distributed to the outputs of 5
Zones. The same function happens to Channel R
.
When button Mono is pressed it Line1(R&L)
signal and Line 2(R&L) signal are mixed altogether and providing
mono signal to output of each correspondent zone. Each channel output
level can be controlled by its corresponding potentiometer.
The low impedance the ZM410 Zone Distribution
Mixer allows long cable runs, and capacitive loads to be driven, without
the bear of signal loss, instability, or frequency response roll off.
Frond panel status LED are provided on the unit
to indicated operation mode, power supply and line source condition. The
unit is supplied in a standard 1U, 19" rack format.
|
